• FOBO TIRE LITE User Manual

Frequently Asked Questions

Do I need to install FOBO TIRE LITE sensors individually?

No, FOBO TIRE LITE sensors come pre-installed in the packaging box. There’s no need to install each sensor separately.

Do I need professional help to install the FOBO TIRE LITE sensors?

No, installation is designed to be DIY and can be completed in less than 2 minutes. Simply scan the QR code found in the packaging box and follow the instructions provided by the app for installation and configuration.

What’s included in the FOBO TIRE LITE set?

• 4 tire sensors (with CR1632 batteries included)
• Anti-theft lock-nuts and wrench
• Free "FOBO TPMS" app, available for download from the Apple App Store or Google Play Store

Which phones are compatible with FOBO TIRE LITE?

FOBO TIRE LITE is compatible with iOS 13 and Android 6.0 or later with Bluetooth 5.0 or higher. Ensure your phone is updated to at least Android 6.0 or iOS 13.

How long do FOBO TIRE LITE batteries last?

FOBO TIRE LITE sensors use CR1632 batteries, which typically last up to 1 year. Battery life may be reduced in extreme temperatures.

How can I prevent my FOBO TIRE LITE sensors from being stolen?

FOBO TIRE LITE features two anti-theft measures: the sensors are not reusable if stolen, and the package includes anti-theft nuts and a wrench for secure installation.

Can FOBO TIRE LITE function without a smartphone?

No, FOBO TIRE LITE requires a smartphone with the FOBO TPMS app installed to monitor tire pressure and temperature. The sensors use Bluetooth 5.0 technology to transmit real-time readings and alerts for any tire anomalies directly to the app. The app is essential for viewing data and receiving notifications about any issues.

Can I monitor tire pressure and temperature with FOBO TIRE LITE sensors without an internet connection?

Yes, you can. FOBO TIRE LITE sensors use Bluetooth technology to communicate directly with your smartphone. An internet connection is only needed for the initial installation and activation of the sensors. Once set up, you can monitor tire pressure and temperature without an active internet connection.

What if a FOBO TIRE LITE sensor gets stolen?

If a FOBO TIRE LITE sensor is stolen, it remains linked to the owner’s email address, preventing it from being used by anyone else. You can purchase a replacement sensor from our web store at www.my-fobo.com.

What if I lose my smartphone?

If you lose your smartphone, you can easily transfer your FOBO TIRE LITE data to a new device. Simply download the FOBO TPMS app on the new smartphone and log in with your existing account. Thanks to CrossPair™ technology, all your details and settings will be seamlessly transferred to the new device.

Is FOBO TIRE LITE sensor suitable for all weather conditions?

Yes, FOBO TIRE LITE sensors are designed to operate in extreme temperatures and are waterproof with an IP57 rating.

Can multiple drivers use FOBO TIRE LITE in the same car?

Yes, you can share FOBO TIRE LITE with others. Use the FOBO share option in the app to add their email addresses, allowing them to sync their account with the FOBO cloud. Ensure they have downloaded the FOBO TPMS app and activated it.

What is the range for detecting FOBO TIRE LITE readings?

FOBO TIRE LITE uses Bluetooth with a typical range of up to 30 meters line-of-sight, depending on obstructions.

Can FOBO TIRE LITE be used for trucks or large vans?

FOBO TIRE LITE is designed for four-wheel vehicles with tire pressures up to 116 psi (800 kPa). Additional sensors can be added for spare tires.

How does FOBO TIRE LITE work when the car engine is off?

FOBO TIRE LITE sensors continuously monitor tire pressure and send signals to your smartphone via Bluetooth, allowing you to check tire pressures at any time, even when the engine is off.

Does FOBO TIRE LITE affect tire balancing?

Each FOBO TIRE LITE sensor weighs 7.6 grams. Testing shows a maximum deviation of 5 grams on wheel balancers, which is within acceptable limits for typical wheel balancing equipment. Rebalancing after installation is not necessary.

What should I do if FOBO TIRE LITE sensors don’t read tire pressure after installation?

If sensors don’t provide readings, ensure the battery tab has been removed and the sensor is installed correctly. If issues persist, remove and reinsert the sensor battery.

Can FOBO TIRE LITE sensors be calibrated?

FOBO TIRE LITE sensors do not require calibration.

Does FOBO TIRE LITE read absolute or gauge pressure?

FOBO TIRE LITE sensors report absolute pressure. The app adjusts these readings to sea-level equivalent, ensuring accuracy regardless of altitude. Inflate tires according to FOBO TIRE LITE readings rather than a handheld gauge if there are discrepancies.

Do I need to reset the system if I change smartphones?

No, simply download the FOBO TPMS app on your new smartphone and log in using your existing email address. All data will sync from our server.

What if I change cars? Do I need to reset the system?

No, just dismount the system from your old car and mount it on your new car. Label each sensor for proper placement and update the car profile in the FOBO TPMS app.

FOBO TIRE LITE Sensor Specification:

• Bluetooth: v5.0
• Transmit Conducted Power: +5.0dBm (sensor)
• Receiver Sensitivity: Conducted Sensitivity -97dBm @ 0.1%BER
• Antenna Return Loss: Typical -9dB
• Operating Frequency: 2.402~2.480 GHz
• Battery Type: CR1632 (sensor). Operating life up to 1 year. (NOTE: The battery operating life varies according to usage and climate temperature)
• Operating Temperature: -40°C to +85°C (sensor), -20°C to +60°C (sensor with common CR1632 batteries)
• Weight: 7.6g (sensor –with battery)
• Sensor Dimension H x D: 13.8mm x 20.2mm
• Maximum Pressure: 800kPa (116psi)
• ESD: 8kV air discharge & 4kV direct contact discharge according to CE standard
• Operating Humidity: up to 90% non-condensing at 40oC
• Dust and Water Proof: IEC60529 compliant to IP57(sensor)
• Sensor structural threshold: 100N ball pressure intensity test
• Mechanical & Environmental Reliability Testing Standards: IEC 60068-2-2, IEC 60068-2-1, ISO 21750, IEC 60068-2-29, IEC 60068-2-5, IEC 60068-2-32, ISO 15184, ISO 2409, SAE J2657, SAEJ113/13
